Technical data
Housing | ABS |
Type of mounting | vertical, Sound outlet opening at bottom |
Cable entry | 7-10 mm |
Connection technology | Terminal up to 2,5 mm² |
Tone | Steady tone |
Volume | 108 dB |
Duty cycle | 100 % |
Operating temperature | -20 °C / +50 °C |
Degree of protection | IP55 |
Weight | 800 g |
Drive system | non-polarised electromagnet, tappet strikes the membranes between 100 and 120 times/sec; DC with electrical contact breaker |
